Use Cases
3.2.3
Example Using Hynix HY27UA081G1M
This section takes you through the configuration steps required to implement Hynix’s HY27UA081G1M
NAND Flash with the EMIF. The following assumptions are made:
•
NAND Flash is connected to chip select space 2 (EM_CS[2])
•
EMIF clock speed is 100 MHZ (t
cyc
= 10 nS)
lists the data sheet specifications for the EMIF and
lists the data sheet specifications
for the NAND Flash.
Table 28. EMIF Timing Requirements for HY27UA081G1M Example
Parameter
Description
Min
Max
Units
t
SU
Data Setup time, data valid before EM_OE high
5
nS
t
H
Data Hold time, data valid after EM_OE high
0
nS
Table 29. NAND Flash Timing Requirements for HY27UA081G1M Example
Parameter
Description
Min
Max
Units
t
RP
Read Pulse width
60
nS
t
REA
Read Enable Access time
60
nS
t
CEA
Chip Enable low to output valid
75
nS
t
CHZ
Chip Enable high to output High-impedance
20
nS
t
RC
Read Cycle time
80
nS
t
RHZ
Read Enable high to output High-impedance
30
nS
t
CLR
Command Latch low to Read enable low
10
nS
t
WP
Write Pulse width
60
nS
t
CLS
CLE Setup time
0
nS
t
ALS
ALE Setup time
0
nS
t
CS
CS Setup time
0
nS
t
DS
Data Setup time
20
nS
t
CLH
CLE Hold time
10
nS
t
ALH
ALE Hold time
10
nS
t
CH
CS Hold time
10
nS
t
DH
Data Hold time
10
nS
t
WC
Write Cycle time
80
nS
