16 16
You can tune the image of any remote computer screen.
To adjust the screen image:
In the OSD main menu, highlight the computer you want to adjust 1.
Press 2. [F5]. The screen image of the selected computer is displayed, along with the Image Tuning label
Adjust the image by pressing 3.  and 
When the image is satisfactory, press 4. [Esc]
Note: Distance affects picture quality. The farther away a remote computer is from the KVM, the lower
the image quality and the more tuning needed. Therefore, put any higher-resolution computers
closer to the KVM.
You can position the OSD label anywhere on the screen.
To position the label from the main window:
Move to the desired computer by pressing 1.  and 
Press 2. [F6]. The selected screen image and identification label are displayed
Use the arrow keys to move the label to the desired position 3.
Press 4. [Esc] to save and exit
With the NetCommander KVM Update software program you can upgrade the firmware for the:
OSD •
NetCommander KVM Switch •
Server Interface Units •
KVM Update enables you to add new features and take advantage of product improvements in a quick
and efficient manner.
6.16 Tuning (F5)
6.17 Moving the Label (F6)
7.2 Upgrading the KVM Firmware
7.1 System Requirements for Firmware Upgrade
6. Operation
(continued)
Pentium 166 or higher with 16MB RAM and 10MB free hard drive space •
Free serial port •
Windows 2000 and later •
To update the firmware, the KVM system must be connected and switched on •
7. Software
