Trango Broadband Wireless — Access5830 User Manual Rev. F page 65
Standard Power Supply
20 Volt DC Power adapter and J-Box supplied with product.
Type:
Linear wall mount transformer
Input: 120 VAC
Output: 20 VDC +/- 1 V
Max current: 1200 mA
FCC Compliance
The transceiver complies with the following regulations:
M5800S-FSU and M5800S-FSU-D: FCC 15.247 Spread Spectrum transmitter
M5300S-FSU: FCC 15.407(2) U-NII Band 2 transmitter
Part 15 Subpart B
Class B Digital device verification
Part 15 Subpart C
FCC 15.203 Antenna connection requirement – non-standard connection
FCC 15.209 Unwanted emissions below 1GHz
FCC 15.207(a) AC conducted emissions 450Khz to 30 MHz
FCC 15.205 Restricted bands (LO and harmonics)= 54 dBuV average @3 meters
M5800S-FSU and M5300S-FSU Antenna Specifications
Type: Patch Array Antenna
Polarization: Vertical, Horizontal electronically selectable
Range: M5800S-FSU: 4 Miles (LOS) from Access5830 AP with 10 dB fade margin
M5300S-FSU: 2 Miles (LOS) from Access5830 AP with 10 dB fade margin
Frequency: 5.2 to 5.9 GHz
Gain: +15 ± 1 dBi
Azimuth Beamwidth: 32 °
Elevation Beamwidth: 18 °
M5800S-FSU-D Antenna Specifications (when mounted on AD5800-25 Reflector Dish)
Type: DSS Style Dish Antenna
Polarization: Vertical, Horizontal electronically selectable
Range: 10 Miles (LOS) from Access5830 AP with 10 dB fade margin
Frequency: 5.7 to 5.9 GHz
Gain: +25 dBi
Azimuth Beamwidth: 9 °
Elevation Beamwidth: 9 °
