Trango Broadband Atlas5010 - Manual

Atlas 5010 Series ™
5.8 GHz High Capacity Backhaul
45 Mbps Wireless Ethernet Bridge
The Atlas 5010 Series™ is a 5.8 GHz point-to-point OFDM wireless Ethernet Bridge capable of sustained throughput
of up to 45 Mbps with outstanding features such as dual-polarity antennas and adaptable rate modulation. This
high-capacity backhaul solution off ers long-range connectivity and exceptional performance at a great value for
wireless Internet service providers (WISPs), Municipal and Enterprise connectivity, Utility SCADA systems, IP-based
surveillance systems, or as a T1/E1 replacement for “last mile” connectivity applications.
Product Highlights
PERFORMANCE & FLEXIBILITY
The Atlas Series is a point-to-point backhaul solution that delivers up to 45 Mbps for the license-exempt
5.8 GHz ISM band. The Atlas Series utilizes a high-performance OFDM radio with a contention-free
point-to-point protocol and user-selectable data rates of 6, 12, 18, 24, 36, 48 and 54 Mbps. Outstanding
features include FEC and ARQ with variable-size sliding window. Packet aggregation allows superior FTP
performance over long transmission ranges.
CHANNEL FLEXIBILITY
The Atlas 5010 has 6 non-overlapping user-changeable channels and. When combined with software-selectable
dual-polarized antennas, exceptional frequency agility can be attained.
INTERFERENCE MITIGATION
The Atlas Series off ers several powerful interference mitigation tools such as site survey tool, adjustable channel center
frequencies and dual-polarity antennas.
COMPACT/RUGGED DESIGN
The Atlas Series radio is designed to withstand the harshest environments, encased in a heavy-duty aluminum housing.
These fully weatherized outdoor units, with rugged conduit adapter, off er a small footprint and operate from -40° F to
140° F. The ATLAS5010-INT radio is integrated onto the backside of a 22-inch dual-polarity patch panel antenna, while
the ATLAS5010-EXT is a stand-alone radio with a connection for an external 2- to 4-foot dual-polarity dish antennas.
Both models are powered using Power-over-Ethernet (PoE) ensuring ease of installation and quick deployment.
SECURITY AND AUTHENTICATION
The Atlas Series features MAC level address authentication, 128-bit proprietary encryption, over-the-air data scrambling
and two-level password control via SSL for secure operation.
MANAGEMENT FEATURES
The Atlas Series enables remote and local management via Telnet, SNMP and HTTP via browser. Powerful tools such as
site survey, asymmetrical bandwidth control, and remote temperature and input voltage measurements allow operators
total control/fl exibility to monitor and manage their network. The radios also feature a built-in LED alignment tool and a
universal mounting bracket to minimize deployment costs.
»
»
»
»
»
»
Up to 45 Mbps
40-mile Range
OFDM, ARQ
•
•
•
INT
EXT
