Trango Broadband Wireless — Access5830 User Manual Rev. F page 61
Appendix C Specifications
M5830S-SU and M5830S-AP-60
All specifications apply to the M5830S-SU and M5830S-AP-60 radios unless otherwise stated.
Radio Transmit Specifications
Frequencies:
Storable Channels:
30 memory locations
Channel spacing: Low Band: 5.260 to 5.340 GHz in 1 MHz increments
High Band: 5.736 to 5.836 GHz in 1 MHz increments
Default Channels-
Channel 1: 5.736 GHz
Channel 2: 5.756 GHz
Channel 3: 5.776 GHz
Channel 4: 5.796 GHz
Channel 5: 5.816 GHz
Channel 6: 5.836 GHz
Channel 7: 5.260 GHz
Channel 8: 5.280 GHz
Channel 9: 5.300 GHz
Channel 10: 5.320 GHz
Channel 11: 5.340 GHz
Channel 12-30: Unprogrammed
AP RF Conducted Power:
Low Band: Max: +16 dBm +/- 2 dB
Min: -8 dBm +/- 2 dB
HighBand: Max: +22 dBm +/- 2 dB
Min: -8 dBm +/- 2 dB
AP EIRP Max: +36 dBm High band with internal 14 dBi patch antenna
+30 dBm Low band with internal 14 dBi patch antenna
SU RF Conducted Power: Low Band: Max: +13 dBm +/- 2 dB
Min: -8 dBm +/- 2 dB
High Band: Max: +22 dBm +/- 2 dB
Min: -8 dBm +/- 2 dB
SU EIRP Max: +40 dBm High band with internal 18 dBi patch antenna (M5830S-SU only)
+30 dBm Low band Maximum
Freq. Stability:
.00025 % PLL Stabilized (2.5 ppm) over temp
Freq. Plan: Single upconversion, 480 MHz IF
Modulated BW: 22 MHz (null to null, 20 dB)
2 nd Harmonic atten: Per CFR47 part 15.205
LO Supression: Per CFR47 part 15.205
Symbol Rate: 1.375 MSPS
Error Correction: None
Modulation: 1 MBPS DBPSK for header, 11 MBPS CCK spread spectrum for payload
Receiver Section
Cascade Noise Figure:
< 6 dB
Sensitivity: - 83 dBm typical-1600 byte packet
(1E10-6 BER) - 87 dBm typical-64 byte packet
Adj. Channel Rejection: > 20 dB for 10 % PER
Image Rejection: > 60 dB for 10% PER
Frequency Plan: Single conversion, IF at 480 MHz
