80X CompactFlash Card
Transcend Information Inc.
V1.1
82
Address Data 7 6 5 4 3 2 1 0 Description of Contents CIS function
12Eh 20h X R P RO A T X=0: no more misc fields
P=1: power-down supported
RO=0:read/write media
A=0: audio not supported
T=0: max twins is 0
TPCE_MI
130h 1Bh CISTPL_CFTABLE_ENTRY Configuration tuple Tuple code
132h 06h CISTPL_LINK Link length is 6 bytes Link to next tuple
134h 03h I D Configuration Index I/O mapped, index=3 TPCE_INDX
136h 01h M MS IR IO T Power Power=1: VCC info, no VPP TPCE_FS
138h 21h R DI PI AI SI HV LV NV PI=1: peak current info
NV=1: nominal voltage info
TPCE_PD
13Ah B5h X Mantissa Exponent X=1: extension byte present
13Ch 1Eh X Extension Nominal voltage 3.30V
13Eh 4Dh X Mantissa Exponent Peak current 45 mA
140h 14h CISTPL_NO_LINK No link control tuple Tuple code
142h 00h CISTPL_LINK Link length is 0 bytes Link to next tuple
144h FFh End of CISTPL_VERS_1 End marker
146h FFh CISTPL_END End of CIS Tuple code
Above technical information is based on industry standard data and tested to be reliable. However, Transcend makes no
warranty, either expressed or implied, as to its accuracy and assumes no liability in connection with the use of this product.
Transcend reserves the right to make changes in specifications at any time without prior notice.
