80X CompactFlash Card
Transcend Information Inc.
V1.1
75
Address Data 7 6 5 4 3 2 1 0 Description of Contents CIS function
07Eh 0Ch Reserved D U S V D=0: single drive on card
U=1: unique serial number
S=1: silicon device
V=00: no VPP required
TPLFE_TYPE
080h 0Fh R I E N P I=0: twin IOIS16# unspecified
E=0: index bit not emulated
N=0: I/O includes 0x3F7
P=F(1111):low power, sleep, standby, idle
supported
TPLFE_TYPE
082h 1Ah CISTPL_CONFIG Configuration Tuple Tuple code
084h 05h TPL_LINK Link length is 5 bytes Link to next tuple
086h 01h RFS RMS RAS RFS: reserved
RMS: 1 byte register mask
RAS: 2 bytes base address
Size of fields
TPCC_SZ
088h 03h TPCC_LAST Last configuration entry is 03H Last entry index
08Ah 00h TPCC_RADR (LSB) Configuration registers are Configuration
08Ch 02h TPCC_RADR (MSB) Located at 0200H Register location
08Eh 0Fh TPCC_RMSK Configuration registers 0 to 3
are present
Configuration register
present mask
090h 1Bh CISTPL_CFTABLE_ENTRY Configuration tuple Tuple code
092h 08h CISTPL_LINK Link length is 8 bytes Link to next tuple
094h C0h I D Configuration Index Memory mapped configuration,
index=0
I=1: Interface byte follows
D=1: Default entry
Configuration Table
Index Byte
TPCE_INDX
096h C0h W R P B Interface type W=1: wait required
R=1: ready/busy active
P=0: WP not used
B=0: BVD1, BVD2 not used
Type=0: Memory interface
Interface
Description
TPCE_IF
