80X CompactFlash Card
Transcend Information Inc.
V1.1
81
Address Data 7 6 5 4 3 2 1 0
Description of Contents
CIS function
116h
99h
M MS IR IO T Power
M=1: misc info present
MS=0: no memory space info
IR=1: interrupt is used
IO=1: I/O space is used
T=0: no timing info specified
Power=1: VCC info, no VPP
TPCE_FS
118h
1h
R DI PI AI SI HV LV NV DI: no power-down current
PI:no peak current info
AI: no average current info
SI: no static current info
HV:no max voltage info
LV:no min voltage info
NV=1: nominal voltage info
TPCE_PD
11Ah
55h
X Mantissa Exponent
Nominal voltage 5.0V
11Ch
EAh R S E IO
R=1: range follows
S=1: support 16 bit hosts
E=1: support 8 bit hosts
IO=10: 10 lines decoded
TPCE_IO
11Eh
61h
LS AS NR
LS=1: 1 byte length
AS=2: 2 byte address
NR=1: 2 address ranges
120h
70h
Base address 1 (LSB)
Address range 1
122h
01h
Base address 1 (MSB)
0x170 to 0x177
124h
07h
Address range 1 length
126h
76h
Base address 2 (LSB)
Address range 2
128h
03h
Base address 2 (MSB)
0x376 to 0x377
12Ah
01h
Address range 2 length
12Ch
EEh
S P L M IRQN
S=1: interrupt sharing logic
P=1: pulse mode supported
L=1: level mode supported
M=0: masks V..N not present
IRQN=14: use interrupt 14
TPCE_IR
