80X CompactFlash Card

Transcend Information Inc.

V1.1

6

PC Card Memory Mode

PC Card I/O Mode

True IDE Mode

4

Pin

Num

Signal Name

Pin

Type

In, Out

Type

Pin

Num

Signal Name

Pin

Type

In, Out

Type

Pin

Num

Signal Name

Pin

Type

In, Out

Type

33

-VS1

O

Ground

33

-VS1

O

Ground

33

-VS1

O

Ground

34

-IORD

I

I3U

34

-IORD

I

I3U

34

-IORD

I

I3Z

35

-IOWR

I

I3U

35

-IOWR

I

I3U

35

-IOWR

I

I3Z

36

-WE

I

I3U

36

-WE

I

I3U

36

-WE

3

I

I3U

37

READY

O

OT1

37

-IREQ

O

OT1

37

INTRQ

O

OZ1

38

VCC

Power

38

VCC

Power

38

VCC

Power

39

-CSEL

5

I

I2Z

39

-CSEL

5

I

I2Z

39

-CSEL

I

I2U

40

-VS2

O

OPEN

40

-VS2

O

OPEN

40

-VS2

O

OPEN

41

RESET

I

I2Z

41

RESET

I

I2Z

41

-RESET

I

I2Z

42

-WAIT

O

OT1

42

-WAIT

O

OT1

42

IORDY

O

ON1

43

-INPACK

O

OT1

43

-INPACK

O

OT1

43

DMARQ

O

OZ1

44

-REG

I

I3U

44

-REG

I

I3U

44

-DMACK

6

I

I3U

45

BVD2

O

OT1

45

-SPKR

O

OT1

45

-DASP

I/O

I1U, ON1

46

BVD1

O

OT1

46

-STSCHG

O

OT1

46

-PDIAG

I/O

I1U, ON1

47

D08

1

I/O

I1Z,

OZ3

47

D08

1

I/O

I1Z,

OZ3

47

D08

1

I/O

I1Z, OZ3

48

D09

1

I/O

I1Z,

OZ3

48

D09

1

I/O

I1Z,

OZ3

48

D09

1

I/O

I1Z, OZ3

49

D10

1

I/O

I1Z,

OZ3

49

D10

1

I/O

I1Z,

OZ3

49

D10

1

I/O

I1Z, OZ3

50

GND

Ground

50

GND

Ground

50

GND

Ground

Note:

1) These signals are required only for 16 bit accesses and not required when installed in 8 bit systems. Devices

should allow for 3-state signals not to consume current.

2) The signal should be grounded by the host.
3) The signal should be tied to VCC by the host.
4) The mode is required for CompactFlash Storage Cards.
5) The -CSEL signal is ignored by the card in PC Card modes. However, because it is not pulled upon the card in these

modes, it should not be left floating by the host in PC Card modes. In these modes, the pin should be connected by the
host to PC Card A25 or grounded by the host.

6) If DMA operations are not used, the signal should be held high or tied to VCC by the host. For proper operation in older

hosts: while DMA operations are not active, the card shall ignore this signal,including a floating condition
