80X CompactFlash Card
Transcend Information Inc.
V1.1
79
Address Data 7 6 5 4 3 2 1 0
Description of Contents
CIS function
0E2h
41h
W R P B Interface type
W=0: wait not required
R=1: ready/busy active
P=0: WP not used
B=0: BVD1, BVD2 not used
Type=1: I/O interface
TPCE_IF
0E4h
99h
M MS IR IO T Power
M=1: misc info present
MS=0: no memory space info
IR=1: interrupt is used
IO=1: I/O space is used
T=0: no timing info specified
Power=1: VCC info, no VPP
TPCE_FS
0E6h
01h
R DI PI AI SI HV LV NV DI: no power-down current
PI:no peak current info
AI: no average current info
SI: no static current info
HV:no max voltage info
LV:no min voltage info
NV=1: nominal voltage info
TPCE_PD
0E8h
55h
X Mantissa Exponent
Nominal voltage 5.0V
0EAh
EAh R S E IO
R=1: range follows
S=1: support 16 bit hosts
E=1: support 8 bit hosts
IO=10: 10 lines decoded
TPCE_IO
0ECh
61h
LS AS NR
LS=1: 1 byte length
AS=2: 2 byte address
NR=1: 2 address ranges
0EEh
F0h Base address 1 (LSB)
Address range 1
0F0h
01h
Base address 1 (MSB)
0x1F0 to 0x1F7
0F2h
07h
Address range 1 length
0F4h
F6h Base address 2 (LSB)
Address range 2
0F6h
03h
Base address 2 (MSB)
0x3F6 to 0x3F7
0F8h
01h
Address range 2 length
