80X CompactFlash Card
Transcend Information Inc.
V1.1
57
mode supported by the card.
Value Maximum Multiword DMA timing mode supported
0 Specified in word 63
1 Multiword DMA Mode 3
2 Multiword DMA Mode 4
3-7 Reserved
Bits 8-6: Advanced True IDE PIO Mode Selected Indicates the current True IDE PIO mode selected on the
card.
Value Current PIO timing mode selected
0 Specified in word 64
1 PIO Mode 5
2 PIO Mode 6
3-7 Reserved
Bits 11-9: Advanced True IDE Multiword DMA Mode Selected Indicates the current True IDE Multiword DMA
Mode Selected on the card.
Value Current Multiword DMA timing mode selected
0 Specified in word 63
1 Multiword DMA Mode 3
2 Multiword DMA Mode 4
3-7 Reserved
Bits 15-12 are reserved.
Word 164: CF Advanced PCMCIA I/O and Memory Timing Modes Capabilities and Settings
This word describes the capabilities and current settings for CFA defined advanced timing modes using the
Memory and PCMCIA I/O interface.
Notice! The use of PCMCIA I/O or Memory modes that are 100ns or faster impose significant restrictions
on the implementation of the host:
Additional Requirements for CF Advanced Timing Modes.
Bits 2-0: Maximum Advanced PCMCIA I/O Mode Support Indicates the maximum I/O timing mode supported
by the card.
Value Maximum PCMCIA IO timing mode Supported
0 255ns Cycle PCMCIA I/O Mode
1 120ns Cycle PCMCIA I/O Mode
2 100ns Cycle PCMCIA I/O Mode
3 80ns Cycle PCMCIA I/O Mode
4-7 Reserved
Bits 5-3: Maximum Memory timing mode supported
Indicates the Maximum Memory timing mode supported by the card.
Value Maximum Memory timing mode Supported
0 250ns Cycle Memory Mode
1 120ns Cycle Memory Mode
2 100ns Cycle Memory Mode
3 80ns Cycle Memory Mode
4-7 Reserved
Bits 15-6 are reserved.
