Transcend Information Transcend CF 80X TS32M~1GCF80 - Manual (Page 76)

T T T S S S 3 3 3 2 2 2 M M M ~ ~ ~ 1 1 1 G G G C C C F F F 8 8 8 0 0 0
80X CompactFlash Card
Transcend Information Inc.
V1.1
76
Address Data 7 6 5 4 3 2 1 0 Description of Contents CIS function
098h A1h M MS IR IO T Power M=1: misc info present
MS=1: 2 byte memory length
IR=0: no interrupt is used
IO=0: no I/O space is used
T=0: no timing info specified
Power=1: VCC info, no VPP
Feature Selection
Byte TPCE_FS
09Ah 01h R DI PI AI SI HV LV NV DI: no power-down current
PI:no peak current info
AI: no average current info
SI: no static current info
HV:no max voltage info
LV:no min voltage info
NV=1: nominal voltage info
Power Description
Structure Parameter
Selection Byte
TPCE_PD
09Ch 55h X Mantissa Exponent Nominal voltage 5.0V
09Eh 08h Length in 256 byte units (LSB) Length of memory space is 2 Memory space
0A0h 00h Length in 256 byte units (MSB) Kbyte descr. TPCE_MS
0A2h 20h X R P RO A T X=0: no more misc fields
P=1: power-down supported
RO=0:read/write media
A=0: audio not supported
T=0: max twins is 0
Miscellaneous
features TPCE_MI
0A4h 1Bh CISTPL_CFTABLE_ENTRY Configuration tuple Tuple code
0A6h 06h CISTPL_LINK Link length is 6 bytes Link to next tuple
0A8h 00h I D Configuration Index Memory mapped configuration,
index=0
TPCE_INDX
0AAh 01h M MS IR IO T Power Power=1: VCC info, no VPP TPCE_FS
0ACh 21h R DI PI AI SI HV LV NV PI=1: peak current info
NV=1: nominal voltage info
TPCE_PD
0AEh B5h X Mantissa Exponent X=1: extension byte present
0B0h 1Eh X Extension Nominal voltage 3.30V
0B2h 4Dh X Mantissa Exponent Peak current 45 mA
