80X CompactFlash Card
Transcend Information Inc.
V1.1
80
Address Data 7 6 5 4 3 2 1 0 Description of Contents CIS function
0FAh EEh S P L M IRQN S=1: interrupt sharing logic
P=1: pulse mode supported
L=1: level mode supported
M=0: masks V..N not present
IRQN=14: use interrupt 14
TPCE_IR
0FCh 20h X R P RO A T X=0: no more misc fields
P=1: power-down supported
RO=0:read/write media
A=0: audio not supported
T=1: max twins is 0
TPCE_MI
0FEh 1Bh CISTPL_CFTABLE_ENTRY Configuration tuple Tuple code
100h 06h CISTPL_LINK Link length is 6 bytes Link to next tuple
102h 02h I D Configuration Index I/O mapped, index=2 TPCE_INDX
104h 01h M MS IR IO T Power Power=1: VCC info, no VPP TPCE_FS
106h 21h R DI PI AI SI HV LV NV PI=1: peak current info
NV=1: nominal voltage info
TPCE_PD
108h B5h X Mantissa Exponent X=1: extension byte present
10Ah 1Eh X Extension Nominal voltage 3.30V
10Ch 4Dh X Mantissa Exponent Peak current 45 mA
10Eh 1Bh CISTPL_CFTABLE_ENTRY Configuration tuple Tuple code
110h 0Fh CISTPL_LINK Link length is 15 bytes Link to next tuple
112h C3h I D Configuration Index I/O mapped, index=3
I=1: Interface byte follows
D=1: Default entry
TPCE_INDX
114h 41h W R P B Interface type W=0: wait not required
R=1: ready/busy active
P=0: WP not used
B=0: BVD1, BVD2 not used
Type=1: I/O interface
TPCE_IF
