80X CompactFlash Card
Transcend Information Inc.
V1.1
77
Address Data 7 6 5 4 3 2 1 0
Description of Contents
CIS function
0B4h
1Bh CISTPL_CFTABLE_ENTRY
Configuration tuple
Tuple code
0B6h
0Ah CISTPL_LINK
Link length is 10 bytes
Link to next tuple
0B8h
C1h I D Configuration Index
I/O mapped, index=1
I=1: Interface byte follows
D=1: Default entry
TPCE_INDX
0BAh
41h
W R P B Interface type
W=0: wait not required
R=1: ready/busy active
P=0: WP not used
B=0: BVD1, BVD2 not used
Type=1: I/O interface
TPCE_IF
0BCh
99h
M MS IR IO T Power
M=1: misc info present
MS=0: no memory space info
IR=1: interrupt is used
IO=1: I/O space is used
T=0: no timing info specified
Power=1: VCC info, no VPP
TPCE_FS
0BEh
01h
R DI PI AI SI HV LV NV DI: no power-down current
PI: no peak current info
AI: no average current info
SI: no static current info
HV:no max voltage info
LV:no min voltage info
NV=1: nominal voltage info
TPCE_PD
0C0h
55h
X Mantissa Exponent
Nominal voltage 5.0V
0C2h
64h
R S E IO
S =1: support 16 bit hosts
E =1: support 8 bit hosts
IO=4: 4 address lines decoded
TPCE_IO
