80X CompactFlash Card
Transcend Information Inc.
V1.1
78
Address Data 7 6 5 4 3 2 1 0 Description of Contents CIS function
0C4h F0h S P L M V B I N S=1: interrupt sharing logic
P=1: pulse mode supported
L=1: level mode supported
M=1: masks V..N present
V=0: no vendor unique IRQ
B=0: no bus error IRQ
I=0: no I/O check IRQ
N=0: no NMI
TPCE_IR
0C6h FFh IRQ7..0 Interrupt signal may be
0C8h FFh IRQ15..8 Assigned to any host IRQ
0CAh 20h X R P RO A T X=0: no more misc fields
P=1: power-down supported
RO=0:read/write media
A=0: audio not supported
T=0: max twins is 0
TPCE_MI
0CCh 1Bh CISTPL_CFTABLE_ENTRY Configuration tuple Tuple code
0CEh 06h CISTPL_LINK Link length is 6 bytes Link to next tuple
0D0h 01h I D Configuration Index I/O mapped, index=1 TPCE_INDX
0D2h 01h M MS IR IO T Power Power=1: VCC info, no VPP TPCE_FS
0D4h 21h R DI PI AI SI HV LV NV PI=1: peak current info
NV=1: nominal voltage info
TPCE_PD
0D6h B5h X Mantissa Exponent X=1: extension byte present
0D8h 1Eh X Extension Nominal voltage 3.30V
0DAh 4Dh X Mantissa Exponent Peak current 45 mA
0DCh 1Bh CISTPL_CFTABLE_ENTRY Configuration tuple Tuple code
0DEh 0Fh CISTPL_LINK Link length is 15 bytes Link to next tuple
0E0h C2h I D Configuration Index I/O mapped, index=2
I =1: Interface byte follows
D=1: Default entry
TPCE_INDX
