E6581315
41
Com-
munica-
tion
Number.
Title Function Adjustment range Unit
Default
setting
Valid Reference
0826 
Inverter-to-inverter
communication
setting
(4-wire
RS485)
0:Slave (issues a 0Hz command if some-
thing goes wrong with the master)
1:Slave (continues operation if something
goes wrong with the master)
2:Slave (trips for emergency stop if
something goes wrong with the master)
3:Master (sends a frequency command)
4:Master (sends an output frequency)
5.Master (sends a torque command)
6.Master (sends an output torque com-
mand)
- 0 After reset. Chapter 6
0829 
Protocol selection
(4-wire RS485) 0: TOSHIBA
1: MODBUS-RTU
- 0 After reset. Chapter 3
0870  Block write data 1
0871  Block write data 2
0: Deselect
1: Command information 1 (FA00)
2: Command information 2 (FA20)
3: Frequency command (FA01)
4: Terminal board output data
(FA50)
5: Communication analog data
(FA51)
- 0 After reset.
Section
4.1.3
0875  Block read data 1
0876  Block read data 2
0877  Block read data 3
0878  Block read data 4
0879  Block read data 5
0: Deselect
1: Status information (FD01)
2: Output frequency (FD00)
3: Output current (FD03)
4: Output voltage (FD05)
5: Alarm information (FC91)
6: PID feedback value (FD22)
7: Input terminal board monitor (FD06)
8: Output terminal board monitor (FD07)
9: VI/IIterminal board monitor (FE36)
10: RR/S4 terminal board monitor (FE35)
11:RX terminal board monitor (FE37)
12:Input voltage (DC detection) (FD04)
13:Speed feedback frequency (FD16)
14:Torque (FD18)
15:MY monitor 1 (FE60)
16:MY monitor 2 (FE61)
17:MY monitor 3 (FE62)
18:MY monitor 4 (FE63)
19:Free notes (F880)
- 0 After reset.
Section
4.1.3
0880  Free notes 0-65535 1 0 Real time Section 7.5
