Video parameters:
Input:
Input level
FBAS 1 Vs-s +/- 0,3 dB into 75
Ohms
Input level RED 0,7 Vs-s +/- 0,1Vs-s into 75 Ohms
Input level GREEN 0,7 Vs-s +/- 0,1Vs-s into 75 Ohms
Input level BLUE 0,7 Vs-s +/- 0,1Vs-s into 75 Ohms
Teletext
Teletext filtering
corresponding to ETS 300 472
standard
Display teletext data (FBAS) corresponding to ITU-R
BT.653-2 lines: 6-22 and 320-335
TV-SCART:
Output:
switchable FBAS or RGB
VCR-SCART:
Input:
FBAS or RGB
Output: FBAS
Serial interface RS 232:
Type
RS 232, bi-directional
Bit rate 115 kBit/s
Connectior D-SUB-socket, 9 pin
Function Update f.operating software
LNB power supply:
LNB power
400 mA max.; double-
insulated
LNB voltage vertical <14,0V no load, > 11,5 V at 400
mA
LNB voltage horiz. < 20V no load, > 17,2 V
at 400 mA
LNB switched off in stand-by mode
22 kHz modulation: 22 kHz, Amplitude 0.6 V +/- 0.2 V
Programme memory:
999 TV programmes
999 RADIO programmes
DiSEqC Control:
DiSEqC 1.0 and DiSEqC 1.2
EPG data:
EPG preview
Timer:
32 events one year ahaead
OSD languages:
German, English
Remote control system
RC-5
Subsystem adress 10 (SAT 2)
Modulation frequency 36 kHz
Infrared wavelengthe 950 nm
