4220 Flow Meter
Appendix C Programming Worksheets
C-3
43. Rain Gauge: Inches, MM, Not Measured
44. pH Units Of Measure: pH, Not Measured
45. D. O. Units: MG/L, PPM, Not Measured
46. Temperature Units: Deg F, Deg. C, (Not Measured)
47. YSI-pH Units Of Measure: pH, Not Measured
48. YSI-D.O. Units: MG/L, PPM, Not Measured
49. YSI-Conductivity Parameter: Specific Conductivity, Salin-
ity, Conductivity, T.D. S.
________Units________Coeff._______
50. YSI-Temperature: Deg F, Deg. C, (Not Measured)
C.2 Flow Conversion:
Level-to-Flow Rate
1. Flow Conversion Type: Weir/flume, Equation, Manning,
Data Points,
2. Type Of Device: Weir, Flume
3. Select Type Of Weir: V-notch, Rectangular, Cipolletti
4. Select V-notch Weir Angle (In Degrees): 22.5, 30, 45, 60, 90,
120,
5. End Contractions On Rectangular Weir: Yes, No
6. Rect. Weir With End Contractions: Enter Crest Length
___._____ Feet (or meters)
7. Cipolletti Weir: Enter Crest Length___._____Feet (or
meters)
8. Type Of Flume: Palmer-Bowlus, Parshall, Trapezoidal, H,
HS, HL, Leopold-Lagco
9. Palmer-Bowlus Size: 4", 6", 8", 9", 10", 12", 15", 18", 21",
24", 27", 30", 48"
10. Parshall Size: 1", 2", 3", 6", 9", 1.0', 1.5', 2.0', 3', 4', 5', 6', 8',
10', 12’'
11. Trapez. Size: LG 60 V, 2" 45 WSC, 45 SRCRC, XL 60
12. Flume Size:.5',.75', 1', 2', 2.5' 3', 4.5'
13. HS Flume Size: 0.4', 0.5', 0.6', 0.8', 1.0
14. HL Flume Size: 2.0', 2.5', 3.0', 3.5', 4.0
15. Leopold-Lagco Flume Size: 4", 6", 8", 10", 12", 15", 18", 21",
24”, 30”
16. Enter Equation Units: Q = ___.___H^___ + ___.___H^___
(Q = kH
P1
+ kH
P2
)
(Note that if your equation does not have a second term,
(kH
P2
), just enter 0 (zero) for it.)
17. Manning Types: Round Pipe, U-channel, Rectangular,
Trapezoid
18. Mann. Round Pipe: Slope = _.______Rough = _.______
19. Mann. Round Pipe: Diameter = _.___Feet (or meters)
20. Mann. U-channel: Slope = __.____Rough = __.____
21. Mann. U-channel: Width = __.____ Feet (or meters)
