4220 Flow Meter
Appendix C Programming Worksheets
C-2
7. YSI 600 Reading Interval: Continuous, 15 Sec, 30 Sec,
1Min, 2 Min, 5 Min
8. Level Enable/Alarm: Hysteresis ________Feet (Or Meters)
9. Flow Rate Enable/Alarm Hysteresis _______Units______
10. Temperature Enable/Alarm Hysteresis ______Deg. F (C)
11. pH Enable/Alarm Hysteresis ________pH units.
12. D.O. Enable/Alarm Hysteresis ________ppm.
13. YSI-pH Enable/Alarm Hysteresis ________pH units.
14. YSI-D.O. Enable/Alarm Hysteresis ________ppm/mg./L
15. YSI-Conductivity Enable /Alarm Hysteresis_______mS/cm
16. YSI-Temperature Enable/Alarm Hysteresis______Deg.
17. Optional Outputs: 4-20 Ma Output, Serial Output, Alarm
Box, Mechanical Totalizer
18. Report Setup, Report A: Flow, D.O./pH, YSI 600, Sample
History, Flow Meter History
19. Level In Report: Yes, No
20. Flow Rate In Report: Yes, No
21. Rainfall In Report: Yes, No
22. pH or D.O. In Report: Yes, No
23. Temperature In Report: Yes, No
24. YSI 600 Data in Report: Yes, No
25. Sample History In Report: Yes, No
26. Flow Meter History In Report: Yes, No
27. Report Setup, Report B: Flow, D.O./pH, YSI 600, Sample
History, Flow Meter History
28. Level In Report: Yes, No
29. Flow Rate In Report: Yes, No
30. Rainfall In Report: Yes, No
31. pH or D.O. In Report: Yes, No
32. Temperature In Report: Yes, No
33. YSI 600 Data in Report: Yes, No
34. Sample History In Report: Yes, No
35. Setup Options: Status, Report Setup, LCD Backlight
36. LCD Backlight Mode: Time-out, Continuous, Off
37. Language: English, French, German, Spanish
38. Program Lock: On, Off
39. Select Option: Program, Setup. This time, select Program
and do the following (Program Section)
40. Units Of Level Measure: Ft., In, M, mm, Not Measured
41. Flow Rate Units of Measure: GPS, GPM, GPH, MGD, CFS,
CFM, CFH, CFD, LPS, M3S, M3M, M3H, M3D, AFD
42. Totalized Volume Units: GAL, MGAL, CF, L, M3, AF
