Specifications
PCS -1/1P
3-207-456-12 (1)
I:\3207456121PCS1WW\09OTH.FM masterpage:Left
PCS-DSB1 Data Solution Box (RGB OUT)
• While the picture input from the RGB IN A or RGB IN B connector is transmitted,
the picture of the input signal format (VGA, SVGA or XGA) is output from this
connector.
Picture element Signal format fH (kHz) fV (Hz) Dot clock
(MHz) Sync
1024 × 768 XGA VESA 60 Hz 48.363 60.004 65 H-neg V-neg
