Copyright © 2005 TOSHIBA CORPORATION. All rights reserved. 132
(E) 52/62HMX95
Chapter 13: Appendix
Video/Audio Terminals (continued)
HDMI ™ INPUT:
HDMI compliant (type A connector)
HDCP compliant
E-EDID** compliant
Suggested formats: 1080i, 480p, 480i, 720p
HDMI Audio: 2-channel PCM; 32/44.1/48 kHz sampling
frequency; 16/20/24 bits per sample
VIDEO/AUDIO OUTPUT (also for recording):
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
2.2 k ohm or less)
VARIABLE AUDIO OUTPUT:
0–300 mV(rms) (30% modulation equivalent,
2.2 k ohm or less)
G-LINK ® :
3 V(p-p), 3.5 mm mono socket (IR blaster cables supplied)
IEEE1394 INPUT/OUTPUT:
IEEE1394 compliant 4-pin
DIGITAL AUDIO OUTPUT:
Optical type
PC VIDEO IN:
Mini D-sub 15-pin Analog RGB
PC AUDIO IN: 150 mV(rms) 22 k ohm or greater
TheaterNet ™ :
OUTPUT: 3 V (p-p), 10 k ohm
INPUT: 3 V (p-p) to 5 V (p-p), pulse code modulated
(Toshiba TV code) over 38 kHz carrier
RJ-45 port:
Standard Ethernet (RJ-45)
Dimensions
52HMX95: Width: 58-3/8 inches (1,483 mm)
Height: 35-1/16 inches (891 mm)
Depth: 15-5/16 inches (389 mm)
62HMX95: Width: 67-1/16 inches (1,703 mm)
Height: 40-15/16 inches (1,040 mm)
Depth: 18-1/4 inches (464 mm)
Weight
52HMX95: 87 lbs (39.5 kg)
62HMX95: 103 lbs (46.7 kg)
Supplied Accessories
• Two dual-wand IR blaster cables
• Remote control with two size “AA” alkaline batteries
• Owner’s manual (this book)
Optional Stands:
52HMX95: ST5275
62HMX95: ST6275
_________
** E-EDID = Enhanced-Extended Display Identification
Specifications
NOTE:
• This model complies with the specifications listed below.
• Designs and specifications are subject to change without notice.
• This model may not be compatible with features and/or specifications that may be added in the future.
Television System
NTSC standard
ATSC standard (8VSB)
Digital Cable (64 QAM, 256 QAM; in-the-clear, unencrypted*)
*Encrypted channels can be viewed on this TV
using a CableCARD.™ See page 14 for details.
Channel Coverage
VHF: 2 through 13
UHF: 14 through 69
Cable TV: Mid band (A-8 through A-1, A through I)
Super band (J through W)
Hyper band (AA through ZZ, AAA, BBB)
Ultra band (65 through 94, 100 through 135)
Power Source
120 V AC, 60 Hz
Power Consumption
240 W (average)
38 W in standby mode (using a CableCARD
™ )
34 W in standby mode (without a CableCARD ™ )
Audio Power
15 W + 15 W
Speaker Type
Main: Two 4 inch (10 cm) round
Tweeter: Two 1-5/8 inch (4 cm) round
Video/Audio Terminals
S-VIDEO INPUT:
Y: 1 V(p-p), 75 ohm, negative sync.
C: 0.286 V(p-p) (burst signal), 75 ohm
VIDEO/AUDIO INPUT:
VIDEO: 1 V(p-p), 75 ohm, negative sync.
AUDIO: 150 mV(rms) (30% modulation equivalent,
22 k ohm or greater)
ColorStream ® (component video) HD INPUT:
VIDEO: Y: 1V(p-p), 75 ohm
P R : 0.7 V(p-p), 75 ohm
P
B
: 0.7 V(p-p), 75 ohm
Suggested formats: 1080i, 480p, 480i, 720p
AUDIO: 150 mV(rms), 22 k ohm or greater
