50
Viewing Image
If both the IP and password you entered are correct, the network viewer appears as shown below.
QUIT: Click to exit the program
at any time.
System status indicators
Green Light: KV-HD01 working normally.
Red Light: KV-HD01 is busy.
HDD 1: Accessed HDD of
the KV-HD01
PLAY LIST:
Click on a specific list
of the recorded video
first and click SUMBIT
PgUp & PgUp:
To scroll up and down the
list of recorded Video.
STATUS: Indicating the
KV-HD01 status.
LIVE: Display live image.
REC: Recording
PLAYBACK: Play
back a
recorded video.
STOP: Click to stop a
playback or
recording.
PLAY: Click to play
back a latest
recorded video
PAUSE: Click to
freeze a play back
image.
REC: Click to activate
recording function of
the KV-HD01
SAVE: Click to save a
viewing image into
the local computer.
LOGOUT: Click to
exit the browsing
software.
SETUP: Click to enter
the MAIN MENU
(Please refer to next
paragraph)
TIME SEARCH:
Enter a specific time you
need to search and click
GO tab.
Year/Month/Day
Hour/ Minute
