5.4 ALARM SETTING
This menu allows users to program the configuration of alarm recording only when an alarm input is
activated. The device will record as long as the alarm input is activated.
ALM OPERATION:
The ALM OPERATION option is used to determine whether to activate/deactivate the alarm
recording when it detects an alarm input.
ON: The device activates the alarm recording when it detects an alarm input.
OFF: The device ignores the alarm signal when it detects an alarm input.
REC RATE:
The REC RATE option is used for adjusting the number of pictures recorded every second into a
hard disk when an alarm input is activated. For a NTSC unit, there are 5 different record speeds
you can select from: 60F/S (60 fields per second), 20F/S, 10F/S, 5F/S, and REMAIN. And for a
PAL unit, there are 5 different record speeds you can select from: 50F/S (50 fields per second),
25F/S, 10F/S, 6.25F/S and REMAIN. If you select REMAIN for use, the device will record
images at the same speed as set on the REC page.
REC QUALITY:
The REC QUALITY option is used to determine the quality of the image being recorded. There
are 3 levels of image quality you can select from HIGH, STANDARD, and BASIC. Selecting
HIGH image quality will result in higher-resolution recorded images, and will normally take up
more storage space than a STANDARD or BASIC quality image does. The table below shows
the level of image quality with the corresponding compression ratio and image size.
MAIN MENU
TIME/ TITLE
RECORD TIMER
RECORD
ALARM
COMMUNICATION
DISK
SYSTEM
GO TO ALARM PAGE ALARM SETTING
ALM OPERATION : OFF
REC RATE
: 60 F/S
REC QUALITY : HIGH
ALM TYPE : NO
ALM DURATION : NON STOP
PRE-ALARM : OFF
MAIN PAGE
ALARM REC ENABLE
