Installing the device drivers

Quatech SDS User’s Manual

Page 44

940-0183-154

October 2006

Figure 41 - Network Connectivity Test Failed screen

Step

Procedure

Description

Step 55

Select one of the following options:

¾

Correct the SDS network

configuration and retest. Press Next to

continue.

¾

Move the SDS to a different subnet

and retest. Press Next to continue.


¾

Ignore the problem and continue

installation. Press Next to continue.

Click Back to retest current configuration.
If you are not sure of the configuration

parameters, consult your system

administrator. The Internet Protocol
(TCP/IP) Properties dialog box displays.

Go to □ Step 32.

Check with your system administrator
for the subnet address. The Locate the

Serial Device Server on remote subnet

screen displays.

Go to □ Step 45.

The TCP/IP Network Configuration

Parameters screen displays.

Go to □ Step 16.

Figure 42 displays when the
IP connection test fails. It

presents you with these three

options:

¾

Change the SDS’ IP

configuration and retest

¾

Move the SDS to a

different location and retest

¾

Ignore the problem and

continue installing
