Appendix E
CONNECTOR PIN-OUTS
RS-232 Port, Standard DB-9P
Connector Pin
Direction
Signal (TTL level)
1
No Connection
3
To Omni
Receive Data (RxD)
2
To Host
Transmit Data (TxD)
5
Signal Ground
8
To Host
Request To Send (RTS)
7
To Omni
Clear To Send (CTS)
9
No Connection
