42
EXAMPLE TWO
*AST798X*
Symbology Code 39
Desired Output: The input record must be Code 39 and be exactly seven
characters in length with the seventh character being an “X”. It is divided into
three fields; the first three characters, the next three characters, and the last
character. The output should reverse the order of the first two fields, delete the
last character, and add an (ASCII code 03) at the end of each field. In
addition, a time delay of 900 milliseconds should be added between the fields
(after the F1) and another delay of 2000 milliseconds added to the end of the
record.
Formula ID e LEN 07 07 M 07 X C 03 C 03 A \ 03
SEND BD DLY 09 AD DLY 20
Field List Field A AST
Field B 798
Field C X
Field D
Keystroke Sequence
Enter Data Editing Setup /E/D/FJ
Enter Data Editing and Enable JA1
Enter Code ID and e (for Code 39) JCe
Enter Length and 0707 JD070
< ENTER >7
Enter Match and 07X JE07
X
Enter Count and 03 JF03
Enter Count and 03 JF03
Enter Add Field &
character JJ^C *
Enter Field Sequence and BD JKBD
Enter Add Delay and 09 JM0
9
Enter Field Sequence and AD JKAD
Enter Add Delay and 20 JM2
0
Enter Exit Setup JZ
Output Data 798<>.9s delay AST<>
2s delay
* ^C: Do a CTRL-C by holding down the key while pressing the C key, then
releasing both.
