41
5. If UNMATCHED INPUT is set to SEND, the unmatched data is passed on
to the message processing section of the reader, where any previously-defined
postamble, preamble, and terminator characters are added before the data is
sent to the output port.
Examples
EXAMPLE ONE
76440057320712
Symbology Code 128
Desired Output: Divide the input data record into two fields with one consist-
ing of the first six digits and the second containing the remaining data. The
output should have a or inserted after each
field.
Formula ID h C 06 A SEND ACBC
Field List Field A 764400
Field B 57320712
Field C
Keystroke Sequence
Enter Data Editing Setup /E/D/FJ
Enable Data Editing JA1
Enter Code ID as h (for Code 128) JCh
Define first six characters as Field A,
and remaining data as Field B JF0
6
Enter Add Field C as the key JJ^N*
Define Field Sending Sequence of ACBC JKA
C< ENTER>B
C
Save Exit Setup JZ
Output Data 764400
57320712
* ^N: Do a CTRL-N by holding down the key while pressing the N key, then
releasing both.
