Ordering Information
Basic I/O Units
■ Output Units
Note: Connectors are not provided with these connector models. Either purchase one of the following 40-pin connectors, or use an OMRON XW2 @
Connector-Terminal Block Conversion Unit or a G7 @ I/O Relay Terminal.
Unit
classi-
fica-
tion
Product
name
Specifications No. of
words
allo-
cated
Current con-
sumption (A)
Model Standards
I/O
points
Maximum
switching
capacity
Commons Additional
functions
External
connec-
tion
5 V 24 V
CJ1
Basic
I/O
Units Relay
Contact
Output
Units 8 out-
puts 250 VAC/
24 VDC, 2 A Indepen-
dent con-
tacts None Remov-
able termi-
nal block 1 word 0.09 0.048
max. CJ1W-OC201 UC1, N, L,
CE
16 out-
puts 250 VAC/
24 VDC, 2 A 16 points,
1 common Remov-
able termi-
nal block 1 word 0.11 0.096
max. CJ1W-OC211
Transis-
tor Out-
put
Units 8 out-
puts 12 to 24 VDC,
2 A, sinking 4 points,
1 common Remov-
able termi-
nal block 1 word 0.09 --- CJ1W-OD201
8 out-
puts 24 VDC, 2 A,
sourcing 4 points,
1 common Short-
circuit pro-
tection,
disconnec-
tion detec-
tion Remov-
able termi-
nal block 1 word 0.11 --- CJ1W-OD202
8 out-
puts 12 to 24 VDC,
0.5 A, sinking 8 points,
1 common None Remov-
able termi-
nal block 1 word 0.10 --- CJ1W-OD203
8 out-
puts 24 VDC, 0.5 A
sourcing
8 points,
1 common Short-
circuit
protection Remov-
able termi-
nal block 1 word 0.10 --- CJ1W-OD204
16 out-
puts 12 to 24 VDC,
0.5 A, sinking 16 points,
1 common None Remov-
able termi-
nal block 1 word 0.10 --- CJ1W-OD211
16 out-
puts 24 VDC, 0.5 A,
sourcing
16 points,
1 common Short-cir-
cuit protec-
tion Remov-
able termi-
nal block 1 word 0.10 --- CJ1W-OD212
32 out-
puts 12 to 24 VDC,
0.5 A, sinking 16 points,
1 common None Fujitsu
connector 2 words 0.14 --- CJ1W-OD231
(See note.)
32 out-
puts 24 VDC, 0.5 A,
sourcing
16 points,
1 common Short-
circuit
protection MIL con-
nector 2 words 0.15 --- CJ1W-OD232
(See note.)
32 out-
puts 12 to 24 VDC,
0.5 A, sinking 16 points,
1 common None MIL con-
nector 2 words 0.14 --- CJ1W-OD233
(See note.)
64 out-
puts 12 to 24 VDC,
0.3 A, sinking 16 points,
1 common None Fujitsu
connector 4 words 0.17 --- CJ1W-OD261
(See note.)
64 out-
puts 24 VDC, 0.3 A,
sourcing 16 points,
1 common None MIL con-
nector 4 words 0.17 --- CJ1W-OD262
(See note.)
64 out-
puts 12 to 24 VDC,
0.3 A, sinking 16 points,
1 common None MIL con-
nector 4 words 0.17 --- CJ1W-OD263
(See note.)
Triac
Output
Units 8 out-
puts 250 VAC, 0.6 A 8 points,
1 common None Remov-
able termi-
nal block 1 word 0.22 --- CJ1W-OA201
