background image

24

Ordering Information

Programming Devices

Programming Devices

Note: Site licenses are also available for users that need to use the CX-One on many computers. Ask your OMRON representative for details.

When purchasing the DVD format, verify the computer model and DVD drive specifications before purchasing.

Product name

Specifications

Model

Standards

Number of

licenses

Media

FA Integrated
Tool Package
CX-One
Ver. 2.

@

The CX-One is a comprehensive software package that integrates
Support Software for OMRON PLCs and components.
CX-One runs on the following OS.
Windows 98 SE, Me, NT4.0 (Service Pack 6a), 2000 (Service Pack
3 or higher), XP, or Vista
CX-One Ver.2.

@ includes CX-Protocol Ver. 1.@, CX-Programmer

Ver.7.

@, CX-Designer Ver. 2.@, and CX-Process Tool Ver. 5.@, and

NS Faceplate Auto-Builder version 3.

@.

1 license

CD

CXONE-AL01C-EV2

---

DVD

CXONE-AL01D-EV2

3 licenses

CD

CXONE-AL03C-EV2

DVD

CXONE-AL03D-EV2

10 licenses

CD

CXONE-AL10C-EV2

DVD

CXONE-AL10D-EV2

30 licenses

CD

CXONE-AL30C-EV2

DVD

CXONE-AL30D-EV2

50 licenses

CD

CXONE-AL50C-EV2

DVD

CXONE-AL50D-EV2

CX-Protocol, CX-Programmer, CX-Designer, CX-Process Tool, and NS Faceplate Auto-Builder can still be ordered individually in the
following model numbers.

CX-Protocol
Ver. 1.

@

Protocol creation software for Windows 98SE, Me, NT4.0 (Service
Pack 6a), 2000 (Service Pack 3 or higher), XP, or Vista
Note: Use with CJ1G/CJ1H CPU Unit version 1.2 or higher, or

CJ1M CPU Unit version 1.3 or higher.

1 license

CD

WS02-PSTC1-E

---

CX-
Programmer
Ver. 7.

@

Windows-based Support Software for ladder programming on Win-
dows 98SE, Me, NT 4.0 (Service Pack 6a), 2000 (Service Pack 3
or higher), XP, or Vista

1 license

CD

WS02-CXPC1-E-V7

@

3 licenses

CD

WS02-CXPC1-E03-V7

@

10 licenses

CD

WS02-CXPC1-E10-V7

@

CX-Designer
Ver. 2.

@

NS-series PT screen creation software for Windows 98SE, Me,
NT4.0 (Service Pack 6a), 2000 (Service Pack 3 or higher), XP, or
Vista
CX-Designer version 2.

@ or higher includes the Ladder Monitor

Software.
Note: The Ladder Monitor software allows ladder programming in

a CS/CJ-series PLC to be monitored on an NS-series PT. To
use System Program version 6.6 or earlier with the NS8/10/
12-V1 or NS8/10/12-V2, a Memory Card and Memory Card
Adapter must be ordered separately.

1 license

CD

NS-CXDC1-V2

CX-Process
Tool Ver. 5.

@

Programming software for Loop Controller for Windows 98SE, Me,
NT4.0 (Service Pack 6a), 2000 (Service Pack 3 or higher), XP, or
Vista

1 license

CD

WS02-LCTC1-EV5

NS Faceplate
Auto-Builder
Ver. 3.

@

Software to automatically creates NS-series PT screens for Win-
dows 98SE, Me, NT4.0 (Service Pack 6a), 2000 (Service Pack 3 or
higher), XP, or Vista

1 license

CD

WS02-NSFC1-EV3

CX-Process
Monitor Plus

Windows-based monitoring software for Loop Controllers for Win-
dows NT 4.0, 2000, or XP

1 license

WS02-LCMC1-EV2

3 licenses

WS02-LCMC1-EV2L03

Peripheral
Device
Connecting
Cables (for
peripheral port)

Connects IBM PC/AT or compatible computers, D-Sub 9-pin receptacle
(Length: 0.1 m) (Conversion cable to connect RS-232C cable to peripheral port)

CS1W-CN118

CE

Connects IBM PC/AT or compatible computers,
D-Sub 9-pin (Length: 2.0 m)

Used for Peripheral Bus
or Host Link.

CS1W-CN226

Connects IBM PC/AT or compatible computers,
D-Sub 9-pin (Length: 6.0 m)

CS1W-CN626

Peripheral
Device
Connecting
Cables (for RS-
232C port)

Connects IBM PC/AT or compatible computers,
D-Sub 9-pin (Length: 2.0 m)

Used for Peripheral Bus
or Host Link.
Anti-static connector

XW2Z-200S-CV

---

Connects IBM PC/AT or compatible computers,
D-Sub 9-pin (Length: 5.0 m)

XW2Z-500S-CV

Connects IBM PC/AT or compatible computers,
D-Sub 9-pin (Length: 2.0 m)

Used for Host Link only.
Peripheral Bus not sup-
ported.

XW2Z-200S-V

Connects IBM PC/AT or compatible computers,
D-Sub 9-pin (Length: 5.0 m)

XW2Z-500S-V

USB-Serial
Conversion
Cable

USB-RS-232C Conversion Cable (Length: 0.5 m) and PC driver (on a CD-ROM disc), Com-
plies with USB Specification 1.1
On personal computer side: USB (A plug connector, male)
On PLC side: RS-232C (D-Sub 9-pin, male)
OS: Windows 98, Me, 2000, or XP

CS1W-CIF31

N
