62
Specification
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
General
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
Specifications and features are subject to change without
notice.
Power Output
2 channels driven:
75 W + 75 W (8 Ω, 20 Hz–20 kHz, FTC)
100 W + 100 W (6 Ω, 1 kHz, FTC)
Dynamic Power 180 W + 180 W (3 Ω, Front)
140 W + 140 W (4 Ω, Front)
95 W + 95 W (8 Ω, Front)
THD (Total Harmonic
Distortion)
0.08% (Power Rated)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and
Impedance
200 mV/ 47 k Ω (LINE)
Output Level and
Impedance
200 mV/ 470 Ω (REC OUT)
Frequency Response 10 Hz–100 kHz/ +1 dB, –3 dB (Direct
mode)
Tone Control ±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 6 Ω–
Input Sensitivity/Output
Level and Impedance
1 Vp-p /75 Ω (Component and S-Video Y)
0.7 Vp-p /75 Ω (Component Pb/Cb, Pr/Cr)
0.28 Vp-p /75 Ω (S-Video C)
1 Vp-p /75 Ω (Composite)
Component Video
Frequency Response
5 Hz – 50 MHz
Tuning Frequency
Range
87.5 MHz– 107.9 MHz
Usable Sensitivity Stereo: 22.2 dBf (75 Ω IHF)
Mono: 15.2 dBf (75 Ω IHF)
Signal to Noise Ratio Stereo: 67 dB (IHF-A)
Mono: 73 dB (IHF-A)
THD Stereo: 0.5% (1 kHz)
Mono: 0.3% (1kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB
Stereo Separation 40 dB (1 kHz)
Tuning Frequency
Range
530 kHz–1710 kHz
Usable Sensitivity 300 µV/m
Signal to Noise Ratio 40 dB
THD 0.70%
Power Supply AC 120 V, 60 Hz
Power Consumption 6.2 A
Standby Power
Consumption
0.1 W
Dimensions
(W
×
H
×
D) 17-1/8"
Ч
5-7/8"
Ч
14-3/4"
435
Ч
150
Ч
374 mm
Weight 20.9 lbs.
9.5 kg
Component DVD, VIDEO1, VIDEO2
S-Video DVD, VIDEO1, VIDEO2
Composite DVD, VIDEO1, VIDEO2, VIDEO3
Component MONITOR
S-Video MONITOR OUT, VIDEO1
Composite MONITOR OUT, VIDEO1
Digital Inputs Optical: 3
Coaxial: 1
Analog Inputs DVD (MULTICHANNEL), VIDEO1,
VIDEO2, VIDEO3, TAPE, CD
Multichannel Input 6 jacks
Analog Outputs TAPE, VIDEO1
Subwoofer Pre Outputs 1
Speaker Outputs
SP A (L, R, C, SL, SR, SBL, SBR)
SP B (L, R)
Phones 1
