25
Connecting Your Components—Continued
Connecting a VCR or DVD Recorder for Recording
Connection AV receiver Signal flow VCR/DVD recorder Picture quality
VIDEO 1 OUT S
⇒
S-Video input Better
VIDEO 1 OUT V
⇒
Composite video input Standard
VIDEO 1 OUT L/R
⇒
Audio L/R input —
Connecting a Camcorder, Games Console, or Other Device
Connection AV receiver Signal flow Camcorder/console
VIDEO 3 INPUT
⇐
Composite video output
VIDEO 3 INPUT L/R
⇐
Analog audio L/R output
L
R
L
R
VIDEO 1
AUDIO
IN
S VIDEO IN
VIDEO IN
VIDEO 1
V
S
VIDEO 1
Step 1: Choose a video connection that matches your VCR or DVD recorder ( or ), and make the connection.
The video source that you want to record must be connected to the AV receiver via the same type of connection.
Step 2: Make audio connection .
A B
a
A
B
a
VCR,
DVD recorder
A
B
a
AUDIO L R
DIMMER MEMORY TUNING MODE RETURN
TUNING / PRESET
ENTER
SETUP
CLEAR
TAPE TUNER CD VIDEO
VIDEO 3 INPUT
MASTER VOLUME
VIDEO OUT
AUDIO
VIDEO 3 INPUT
L R
AUDIO
OUT
L R
VIDEO 3 INPUT
Step 1: Make video connection .
Step 2: Make audio connection .
A
a
A
a
Camcorder, games console, etc.
A
a
