22
Connecting Your Components—Continued
• With connection , you can listen to and record audio from your TV and listen via speaker set B.
• To enjoy Dolby and DTS listening modes, use connection or . (For recording, use and , or and .)
Hint!
If your TV has no audio outputs, connect an audio output from your VCR to the AV receiver and use its tuner to lis-
ten to TV programs through the AV receiver.
Connecting a TV or Projector
Connection AV receiver Signal flow TV Picture quality
COMPONENT VIDEO OUT
⇒
Component video input Best
MONITOR OUT S
⇒
S-Video input Better
MONITOR OUT V
⇒
Composite video input Standard
Connection AV receiver Signal flow TV
VIDEO 2 IN L/R
⇐
Analog audio L/R output
DIGITAL IN COAXIAL
⇐
Digital coaxial output
DIGITAL IN OPTICAL 2
⇐
Digital optical output
Y
P B
P R
Y
P B
P R
COMPONENT VIDEO
COMPONENT VIDEO
S VIDEO IN
IN
VIDEO IN
MONITOR
OUT
V
S
MONITOR
OUT
Step 1: Video Connection
Choose a connection that matches your TV (
, , or ), and then make the connection. A B C
TV, projector,
etc.
A
B
C
A
B
C
OPTICAL
2
OPTICAL
OUT
L
R
L
R
IN
VIDEO 2
AUDIO
OUT
DIGITAL IN
COAXIAL
COAXIAL
OUT
Step 2: Audio Connection
Choose a connection that matches your TV (
, , or ), and then make the connection. a b c
TV, projector,
etc.
a
b
c
Connect one or
the other
a
b c a b a c
a
b
c
