OTC Wireless switch/hub - Manual (Page 56)

46
Post Collision Test
ABS / Air Bag 2004 User Guide
5 Select Read Codes from the Diagnostic Trouble Codes
menu screen and press the ENTER key.
Note: If the Read Codes menu screen appears, select
Current Codes from the menu and press the ENTER key.
This displays the DTC Information screen.
Figure 6.4: DTC Information Screen
6 View the list and save or print it, if necessary.
To view a saved file, refer to “
Playback a Data File ” on
page 21 . For printing information, refer to “ Print ” on
page 26 .
Note: For more information about DTCs and the DTC
Information screen, refer to “
Chapter 5: Diagnostic
Codes (Read / Clear Codes) ” on page 33 .
7 Use the EXIT key to return to previous screens.
8 If necessary, use the Clear Codes function to erase the
codes from the vehicle’s ECU. For details, refer to “
Clear
Codes ” on page 38 .
9 Do any further air bag repairs and repeat the test.
