Runco CL-410 and CL-420 Owner’s Operating Manual
45
ICC Adjust: Use the ICC Adjust controls to customize the stored NTSC, HDTV and/or
PAL color space characteristics. To do this:
1.
Select ICC Adjust from the ISF Calibration menu and press ENTER.
2.
Select the color space to modify using the left- or right-arrow buttons.
3.
Select a component color (Red, Green, Blue, Cyan, Yellow or Magenta).
For each component color, you can adjust the following:
• Intensity: This slidebar adjusts the intensity -- also known as luminance -- of a given
color.
• Saturation: This slidebar adjusts the color saturation level -- the amount of that color
in a video image. Lower settings produce less saturated colors; a setting of “-64”
removes that color from the image entirely. If the saturation is too high, that color will be
overpowering and unrealistic.
• Hue: This slidebar adjusts the red/green color hue for true color reproduction of video
signals. For best results, adjust the hue while displaying an external color bar test
pattern (Figure 4-7).
When you have finished customizing the color space, select Store Setting and press
ENTER.
ISF Enable: Use ISF Enable to control the display of the ISF logo on the CL-410/CL-420
splash screen upon power-up; see Figure 4-11.
Figure 4-11. ISF-Enabled CL-410/CL-420 Splash Screen
ICC Adjust
Color Space
NTSC
Intensity
0
Saturation
0
Hue
0
Store Setting
R
G
B
C
Y
M
CALIBRATED FOR:
CUSTOM BUILT BY:
