3.2
Quick Setup
Table 3-1 gives a quick overview of the CL-410/CL-420 installation process. The sections
following this one provide detailed instructions.
Installation should be performed by a qualified custom video
installation specialist.
Table 3-1. Installation Overview
Step
Procedure
For Details, refer to
page...
1
Choose a location for the projector
2
Connect signal sources to the projector
3
Connect external controller to RS-232 port (optional)
4
Apply power to the projector
5
For rear-screen and/or ceiling-mount installations, select
the proper picture orientation
6
Lens adjustments: projected image size (zoom), position
(shift) and focus
7
Projector calibration: adjust the following for each input,
starting with Component SD; save settings when finished:
• Aspect ratio
• Brightness
• Contrast
• Color level
• Tint
• Input position
Note
