Runco CL-410 and CL-420 Owner’s Operating Manual

Figure 3-5. Horizontal Lens Shift (Example only)

Screen Center

100% Width Lens Shift

(1.0 x W)

50% Width Lens Shift

(0.5 x W)

150% Width Lens Shift

(1.5 x W)

Screen Width (W)

Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular
lens or projector is shown in this example.
