Operation
30 Runco CL-410 and CL-420 Owner’s Operating Manual
Shift To change the projected image position, rotate the vertical and/or horizontal lens shift
dials.
Figure 4-3. Vertical and Horizontal Lens Shift Controls
4.6
Using the On-Screen
Menus To use the on-screen menus:
1. Press MENU to display the Main Menu.
2. To select a menu item, use the up- or down-arrow buttons ( , ) on the remote
control to highlight it.
3. Press the right- or left-arrow button ( or , depending on the OSD position) to
access that menu.
4. Use the up- or down-arrow buttons ( , ) to select the setting you want to change.
5. Press the right- or left-arrow button ( , ) to change that setting;
-- OR --
With some settings, you can press ENTER to hide the OSD menus and display a
slidebar for that setting only. Then, press the right- or left-arrow button (
, ) to
change it.
6. To return to the previous menu, press EXIT.
The CL-410/CL-420 OSD menus are arranged hierarchically, as shown in Figure 4-4.
Depending on the selected input source, some menu options may not be available.
➤
Do not force the lens shift dials beyond their respective ranges. This
may cause the projector to malfunction.
Caution
Lens shift dial
(Horizontal)
Lens shift dial
(Vertical)
