Runco CL-410 and CL-420 Owner’s Operating Manual 27
4.1
Turning on the Power 1. Turn on your source components.
2. Plug the female end of the power cord into the
AC receptacle on the rear of the
CL-410/CL-420 (AC 100V ~ 240V).
3. Connect the other end to your AC power
source. The power indicator lights blue to
indicate that the CL-410/CL-420 is in
“standby” mode.
4. Press the ON button on the remote control to
turn on the projector. The power indicator
turns off.
5. After a brief warm-up period (approximately 10
seconds), the CL-410/CL-420 will start projecting.
4.2
Adjusting the
Projector Height or
Projection Angle When the CL-410/CL-420 is installed upright, you can adjust the projector height or
projection angle by turning the four adjustable feet on the bottom of the projector; see
Figure 4-1. This is useful for correcting the angle of projection when the projector is placed
on an uneven surface or when the screen is at an angle. You can tilt the projector up to
five (5) degrees up or down by adjusting the feet.
The feet are connected to threaded bolts; turn them clockwise to raise the projector or
counterclockwise to lower it.
Figure 4-1. Adjusting the Feet
4. Operation
Tilting the projector may cause keystone distortion. To correct this,
refer to
Keystone Correction on page 43. Note
Adjustment feet
5° max.
5° max.
