3.1.4 PCMCIA Connector (J4)
The M3A-HS19 is provided with a PCMCIA connector (J4).
Figure 3.1.5 shows the pin assignment for the PCMCIA connector (J4).
Board Edge
Top view of
the solder side
1
35
68
34
3.3V PCMCIA ONLY
J4
Figure 3.1.5 Pin assignment for PCMCIA Connector (J4)
