Operational Specifications
3.2.1 Jumpers (JP1 - JP9)
Rev.1.01 Oct.28.2008 3-17
REJ10J1351-0101
3
Table 3.2.1 M3A-HS19 Jumper Settings (JP1)
Jumper no. Setting Description
1-2 PW EN JP1
PCMCIAPWSEL 2-3 PW PIO
Table 3.2.2 M3A-HS19 Jumper Settings (JP2)
Jumper no. Setting Description
1-2 BUF OE JP2
PCMCIABUFOE 2-3 BUF PIO
Table 3.2.3 M3A-HS19 Jumper Settings (JP3)
Jumper no. Setting Description
1-2 1.8 V-fixed power supply voltage (supplied from regulator) JP3
PWRSEL 2-3 External power supply voltage (supplied from J8)
Table 3.2.4 M3A-HS19 Jumper Settings (JP4, JP5)
Jumper no. Setting Description
1-2 TxD1
JP4
2-3 A23
1-2 SCK1
JP5
2-3 A22
Table 3.2.5 M3A-HS19 Jumper Settings (JP6 - JP8)
Jumper no. Setting Description
1-2 WE0
JP6
2-3 HIFWR
1-2 PE19
JP7
2-3 HIFCS
1-2 CE1B
JP8
2-3 HIFDREQ
Table 3.2.6 M3A-HS19 Jumper Settings (JP9)
Jumper no. Setting Description
1-2 AC adapter
JP9
2-3 Power supply connector
indicates the default setting.
Note: Do not make any change with the jumper settings while the M3A-HS19 is operating. Ensure to turn the power OFF
before changing the settings.
