Installation
32 Signature Cinema™ SC-50d/SC-60d Installation/Operation Manual
PRE
L
IMINAR
Y
Component Video Source Connections: Connect your component video sources to
the HD1, HD2 and/or Component/SCART inputs as shown in Figure 3-12.
Figure 3-12. Component Video Source Connections
Video 1 Y Video 2
Video 3 Pr Pb
Component / SCART
Y
G
Pb
B
Pr
R
Pr
R
Pb
B
Y
G
TRIGGERS
1 2
H V
HD1
HD2
H V
Y P
B
P
R
COMPONEN T
VIDEO OUT
BD/DVD
DTV-Set-Top Box
(DTV-STB)
RCA-to-BNC
adapter
