Figure 3-4 . horizontal lens shift (example only), 4. horizontal lens shift (example only), Figure 3-4 – Runco SIGNATURE CINEMA SC-50D User Manual
Page 36: Pre l iminar y
20
Signature Cinema™ SC-50d/SC-60d Installation/Operation Manual
PRE
L
IMINAR
Y
Figure 3-4. Horizontal Lens Shift (EXAMPLE ONLY)
0%
Screen Center
100% Width Lens Shift
(1.0 x W)
50% Width Lens Shift
(0.5 x W)
Screen Width (W)
Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular
lens or projector is used in this example.
