• The instrument and the adapter should be located so
their position does not interfere with their proper venti-
lation.
.................................................................................................
• Always grasp only the plug or the body of the adapter
when plugging into, or unplugging from, an outlet or this
instrument.
.................................................................................................
• Whenever the unit is to remain unused for an extended
period of time, disconnect the adapter.
.................................................................................................
• Try to prevent cords and cables from becoming entan-
gled. Also, all cords and cables should be placed so they
are out of the reach of children.
.................................................................................................
• Never climb on top of, nor place heavy objects on the
unit.
................................................................................................
• Never handle the adapter with wet hands when plugging
into, or unplugging from, an outlet or this unit.
• Before cleaning the unit, turn off the power and unplug
the adapter from the outlet (p. 9).
................................................................................................
• Whenever you suspect the possibility of lightning in your
area, disconnect the adapter from the outlet.
................................................................................................
Contents
1. Panel descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Rear panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Headphone sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2. Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting the adapter . . . . . . . . . . . . . . . . . . . . . . . . . 9
Turning the power on and off. . . . . . . . . . . . . . . . . . . . 9
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Connecting headphones (sold separately) . . . . . . . . . 9
Listening to the demo songs . . . . . . . . . . . . . . . . . . . . 10
3. Playing organ music. . . . . . . . . . . . . . . . . . . . . . . . 11
Registering the MANUAL I division . . . . . . . . . . . . . . 11
Adding the MANUAL II division . . . . . . . . . . . . . . . . . 11
Playing the MANUAL I and II divisions via separate
keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Tremulant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Using the PEDAL division . . . . . . . . . . . . . . . . . . . . . . . 12
Selecting other organ timbres . . . . . . . . . . . . . . . . . . 14
4. Using the orchestral sounds . . . . . . . . . . . . . . . . . 15
Selecting sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Using a sustain pedal . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Orchestra Melody function . . . . . . . . . . . . . . . . . . . . . 15
Using a chime sound . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5. Additional functions . . . . . . . . . . . . . . . . . . . . . . . 16
Adding reverb . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Selecting different tunings . . . . . . . . . . . . . . . . . . . . . 16
Transposing (same fingering, different notes) . . . . . 17
Recording your performance . . . . . . . . . . . . . . . . . . . 18
Using the audio outputs . . . . . . . . . . . . . . . . . . . . . . . 18
6. Using the C-190’s memories . . . . . . . . . . . . . . . . . 19
Saving your settings as registrations. . . . . . . . . . . . . 19
Loading the settings of a memory . . . . . . . . . . . . . . . 19
Saving settings to the global area . . . . . . . . . . . . . . . 19
7. Specialist functions. . . . . . . . . . . . . . . . . . . . . . . . . 20
Windchest Panning . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Changing the volume and brilliance . . . . . . . . . . . . . 20
Assigning other sounds to the tilt tabs. . . . . . . . . . . 21
Initializing your C-190. . . . . . . . . . . . . . . . . . . . . . . . . 22
8. Connecting the C-190 to MIDI devices . . . . . . . . 23
About MIDI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Making the connections . . . . . . . . . . . . . . . . . . . . . . . 23
MIDI functions supported by the C-190. . . . . . . . . . 23
9. Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
10. MIDI Implementation Chart. . . . . . . . . . . . . . . . . 147
