Runco SC-1 Owner’s Operating Manual
71
PRE
L
IMINAR
Y
Use the controls in the Picture Menu to calibrate your SC-1 for optimum picture quality.
The SC-1 has been designed to incorporate setup and calibration standards established
by the Imaging Science Foundation (ISF). The ISF has developed carefully crafted,
industry-recognized standards for optimal video performance and has implemented a
training program for technicians and installers to use these standards to obtain optimal
picture quality from Runco video display devices. Accordingly, Runco recommends that
setup and calibration be performed by an ISF certified installation technician.
All signal types require separate processing. Therefore, you need to calibrate each DHD
Controller input separately. Runco recommends calibrating the inputs in this order:
1. Component SD
2. S-Video 1 / S-Video 2
3. Composite
4. HD/RGB 1 / HD/RGB 2
5. DVI 1 / DVI 2
Virtualwide 2.35
SVC
A 2.35 image is stretched
anamorphically in both direc-
tions to fill a 16:9 image. (The
secondary anamorphic lens then
“stretches” the image back to
2.35:1.)
Virtualwide 2.35 is available only
on SC-1 projectors equipped
with the CineWide option.
Table 4-1. Aspect Ratio Settings (continued)
Aspect Ratio
Remote
Control
Key
Description
2.35:1 Image on
16:9 Screen
2.35:1 Image on
16:9 Screen with
VirtualWide 2.35
2.35:1 Image on
2.35:1 Screen with
VirtualWide 2.35
Brightness
Contrast
Color
Tint
Sharpness
When you change a picture quality setting, save the change to a
preset afterwards. Otherwise, the change will be lost when a
different input is selected. (Picture quality settings are saved for
each input separately.) For information about saving settings, refer
to
Note
