Installation
18 Runco SC-1 Owner’s Operating Manual
PRE
L
IMINAR
Y
3.2
Quick Setup Table 3-1 gives a quick overview of the SC-1 installation process. The sections following
this one provide detailed instructions.
Installation should be performed by a qualified custom video
installation specialist.
Table 3-1. Installation Overview
Step Procedure
For Details, Refer to
page...
1 Choose a location for the projector 19
2 Install primary projection lens, lamp and heat extractor 24
3 Install CineWide lens mounting assembly (stationary base
plate or AutoScope lens motor – optional) 29
4 Mount the projector 31
5 Connect the DHD Controller to the projector 32
6 Connect signal sources to the DHD Controller 34
7 Connect external controller to RS-232 port (optional) 38
8 Connect AutoScope lens motor and/or other equipment to
12-volt trigger outputs (optional) 38
9 Connect power supply/lamp ballast, if separate from
projection head (split-body configuration) 39
10 Apply power to the projector 42, 43
11 For rear-screen installations, select the proper picture
orientation 46
12 Primary lens adjustments: projected image size (zoom),
position (shift) and focus 22, 46
13 Install CineWide anamorphic lens (optional) 48
14 CineWide lens adjustments: p osition, pitch (angle),
geometry and focus
50
15 Calibrate projector input 1 (RGBHV): perform Auto Setup,
then adjust size/position, input levels, brightness/contrast
etc., as needed 53
16 Repeat Step 15 for projector Input 2 (DVI), if used 53
17 Adjust lamp output, as needed 64
18 DHD Controller input calibration: adjust the following for
each DHD Controller input, starting with Component
SD; save settings when finished:
• Aspect ratio
• Color level
• Brightness • Tint
• Contrast • Input position
69 through 76
