Serial Communications
Runco SC-1 Owner’s Operating Manual 99
PRE
L
IMINAR
Y
Aspect Ratio Commands
ANAMORPHIC NA YES Selects the Anamorphic aspect ratio
ASPECT? NA NA Returns current aspect ratio
ASPECTIN? NA NA Returns the input source aspect ratio
ASPECTOUT? NA NA Returns output screen size
CINEMA NA YES Selects the Cinema aspect ratio
LETTERBOX NA YES Selects the Letterbox aspect ratio
OUT169 NA YES Sets the output screen to 1.78:1 (16:9)
OUT235 NA YES Sets the output screen to 2.35:1
STANDARD NA YES Selects the Standard (4:3) aspect ratio
VIRTUALWIDE NA YES Selects the VirtualWide aspect ratio
VIRTUAL235 NA YES Selects the Virtualwide 2.35 aspect ratio
Picture Adjust Commands
BRIGHTNESS -100/100 YES Sets a value for brightness
BRIGHTNESS? NA NA Returns brightness setting value
CHROMADELAY -12/12 YES Sets a value for input color chroma delay
CHROMADELAY? NA NA Returns input color chroma delay setting
COLOR -100/100 YES Sets a value for color
COLOR? NA NA Returns color setting value
CONTRAST -100/100 YES Sets a value for contrast
CONTRAST? NA NA Returns contrast setting value
FILMMODE 0/1 YES Sets Film Mode off (0) or on (1)
FILMMODE? NA NA Returns Film Mode setting (0 = off; 1 = on)
FILTER 0/15 YES Sets a value for input color noise filter
FILTER? NA NA Returns input color noise filter setting
PHASE 0/3 YES Adjusts phase
PHASE? NA NA Returns phase setting value
SHARPNESS -6/6 YES Sets a value for sharpness
SHARPNESS? NA NA Returns sharpness setting value
TINT -100/100 YES Sets a value for tint
TINT? NA NA Returns tint setting value
Table 6-1. Serial Commands (continued)
Command
Parameter
(min/max)
Value
Stored?
Description
