27. attaching the anamorphic lens to the lens ring, Pre l iminar y – Runco SC-1 User Manual
Page 61
Runco SC-1 Owner’s Operating Manual
49
PRE
L
IMINAR
Y
4. Attach the Lens Adapter Ring to the Pitch Adjustment Yoke using the three screws
provided for this purpose; see Figure 3-27. Then, attach the lens to the Lens Adapter
Ring by threading it clockwise.
Figure 3-27. Attaching the Anamorphic Lens to the Lens Ring
LENS THREADS
INTO RING
FO
CU
S
