Raymarine autopilot User Manual
Page 116
Appendix: Using the ST6001+ With Non-150/400 Autopilots
103
Append
ix
2 seconds
2 seconds
(saves changes)
Calibration Mode Overview
100/300 Autopilot Systems
Calibration Mode
1 second
1 second
1 second
Within DISPLAY CAL, COMPASS CAL and DEALER CAL:
-- press disp to move forwards through items
-- use -1, +1, -10, +10 to adjust settings
-- press standby for 2 seconds to save changes
D5486-1
standby
auto
-1 and +1
standby
auto
standby
auto
Vessel type
Calibration lock
Rudder gain
Counter rudder
Align rudder
Rudder limit
Turn rate limit
Cruise speed
Off course alarm angle
AutoTrim
Power steer on/off
Drive type
Rudder damping
Magnetic variation
AutoAdapt
Latitude
WindTrim (Displacement only)
AutoTack (Displacement only)
AutoRelease (Sterndrive only)
Response level
Swing compass
Compass deviation
Align heading
Display bar selection
Heading type
Data pages 1 to 7
