98 ST6001+ Autopilot Control Unit - Owner’s Handbook
7
Ad
ju
stin
g Au
to
pilo
t S
ettin
gs
Dealer Calibration options: Types 150/150G & 400/400G
Calibration
setting
Vessel type
Fa
ct
or
y d
efa
ul
t
Di
sp
la
ce
me
nt
Se
mi
Di
sp
la
ce
me
nt
Pl
ani
ng
St
er
n dr
iv
e (
I/O
)
Wo
rk
b
oa
t
Sa
il b
oat
Yo
u
r s
e
tt
in
g
s
Calibration lock OFF, ON
Vessel type DISPLACE, SEMI DISPLACE, PLANING, STERN DRV,
WORK BOAT, SAIL BOAT
Drive type 3, 4, 5
Rudder alignment -7 to +7
Rudder limit 10 to 40
Rudder gain 1 to 9
Counter rudder 1 to 9
Rudder damping 1 to 9
AutoTrim 0 to 4
Response
1 to 9 (Type 150G/400G)
1 to 3 (Type 150/400)
Turn rate limit 1 to 30
Off course angle 15 to 40
AutoRelease OFF, ON
AutoTack angle 40 to 125
Gybe inhibit OFF, ON
Wind type APPARENT, TRUE
Wind Trim 1 to 9
Cruise speed 4 to 60
AutoAdapt OFF, nth, Sth
Latitude 0 to 80
Variation -30 to +30
Autopilot reset OFF, ON
