2.5 When Using the Emulator for the First Time
If you have purchased this emulation pod newly, it is necessary to download the firmware. The
download procedure is given in Figure 2.3.
Before downloading the firmware, check the emulator debugger is installed and the PC4701 is
connected to the host machine. For more information, see each user's manual of the emulator
debugger and the PC4701.
Figure 2.3 Firmware download procedure when the emulator is used for the first time
To make sure the emulation pod works properly, run the self-checks. For self-check procedures, see
"4.3 Self-checks" (page 49).
See "4.2 Downloading Firmware"
(page 48).
See "3.6 Connecting the PC4701"
(page 41). Connect the PC4701 and this product.
Within 2 seconds of turning the power ON, press the
RESET switch of the PC4701 and check the maintenance
mode is accessed.
Download the firmware using the emulator debugger.
End the emulator debugger and shut the power of the
PC4701 OFF.
